Chauvet Intimidator 475Z LED Spot

Day £45 + VAT
Week £90 + VAT
Add to quote

Quote: £ 45.00 + VAT

The Chauvet Intimidator Spot 475Z is a powerful moving head designed for spotlighting large events. This fixture can adapt to short-throw or long-throw situations, courtesy of its motorized zoom, and it is fitted with an ultra-bright 250 W LED.

Achieve incredible visual effects with dual rotating prisms which split the beam, creating dramatic displays. Intimidator Spot 475Z also comes equipped with dual gobo wheels for gobo morphing and amazing mid-air projections! This feature-packed powerhouse utilises motorized focus to channel crisp projections at almost any distance. Beams stay where you want them with built-in totem mode; the ¼-turn hanging bracket allows for single or dual clamp mounting options. The full-colour LCD display lets you set, save, and recall one scene manually. Intimidator Spot 475Z has powerCON®-compatible power input/output connections for power linking.

Check our full range of movers & scanners for inspiration and alternative specs.

£45.00

Add to quote
SKU: L-MS4-1 Category:

Extremely bright, 250 W LED moving head spot designed for large events

Dual rotating prisms split the beam for great effects and cover a larger area

Dual gobo wheels allow for gobo morphing and amazing mid-air projections

Motorized zoom for short- or long-throw situations

Unique ¼-turn hanging bracket allows for single or dual clamp mounting options

Emit crisp projections at almost any distance using the motorized focus

Beams always remain on the dance floor using the built-in, innovative Totem mode

Convenient, wireless non-DMX control using the optional IRC-6 remote

Set, save, and recall 1 scene manually, directly from the full-color LCD display

powerCON®-compatible power input/output connections for power linking



DMX Channels: 10 or 16

DMX Connectors: 3-pin XLR

Pan and Tilt: 540°/270°

Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt

Colors: 7 + white, split colors, continuous scroll at variable speeds

Gobos: (1): 7 + open (6 metal + 1 glass), rotating, interchangeable, indexing, continuous scroll at variable speeds
(2): 8 + open, continuous scroll at variable speeds

Light Source: 1 LED (white) 250 W, (16.3 A), 50,000 hours life expectancy

Strobe Rate: 0 to 20 Hz

PWM Frequency: 2 kHz

Zoom Angle: (motorized): 13° to 28°

Illuminance: (13°): 106,300 lux @ 2 m
(28°): 23,680 lux @ 2 m
(13°): 14,290 lux @ 5 m
(28°): 3,741 lux @ 5 m

Lumens: 10,433

Power Linking: 5 units @ 230 V

Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)

Power and Current: 380 W, 3.4 A @ 120 V, 60 Hz
378 W, 1.9 A @ 230 V, 50 Hz

Gobo Size: 25.7 mm outside, 21 mm image, 1.3 mm max thickness

Weight: 36.2 lb (16.5 kg)

Size: 14.3 x 9.8 x 20.9 in (363 x 250 x 531 mm)

Approvals: CE, MET

Prism: (1): 6-facet round, bidirectional rotation at variable speeds
(2): 6-facet linear, bidirectional rotation at variable speeds

Intimidator_Spot_475Z_UM_Rev1.pdf
