Astera Helios Tube (55cm) – pack of 8
Brand:
Astera
Get in touch to hire
Day Rate
£150.00 +VAT
Week Rate
£300.00 +VAT
Description
The Astera Helios Tube, at 55cm length, is the baby brother of the Titan and the Hyperion tubes but includes the same high-end features of the larger specs. The Helios Tube is an RGB – Amber – Mint LED lighting fixture. It allows mounting in areas where a Titan Tube wouldn’t fit and also increases portability. Helios has 8 pixels with colours and brightness exactly matched to Titans and Hyperions. This allows you to use all formats together. Helios Tubes fun sized specifications can be used to light your parties, corporate events or film sets.
Product Video
Technical Specifications
Order Code | FP2 | FP2-BTB |
---|---|---|
LED Engine | Titan LED Engine | |
Colors | RGBMintAmber | |
Total LED Power | 36 W | |
LED Power Draw | 24 W | |
Luminous Flux 3200K | 1Â 285 Lumens | |
Luminous Flux 4000K | 1Â 340 Lumens | |
Light Output 3200 K @ 1m | 360 Lux | |
Light Output 4000 K @ 1m | 393 Lux | |
CRI (Ra)/ TLCI 3200- 6500 K | ≥96 | |
Beam Angle | 135° x 115° | |
Field Angle | 135° x 115° | |
Strobe | 0 – 25 Hertz | |
Pixels | 8 | |
Battery Runtime | up to 20 hours | |
Battery Lifetime | 70 % after 300 cycles | |
Charging Time (nominal) | 3 hours | |
DC Input | 24 VDC – 1.25 A | |
DC Connector | 5.5 mm x 2.1 mm | |
Wired DMX | Yes (via FP1-PWBÂ / FP3-DTLÂ / PWB-2-86) | |
CRMX Receiver | Built-in | |
BluetoothBridge BTB | No | Yes |
Wireless Protocols | CRMX, UHF | CRMX, UHF, Bluetooth, WiFi |
Wireless Range | CRMX/UHF Up to 300 m / 330 yds | CRMX/UHF Up to 300 m / 330 yds Bluetooth Up to 3 m / 3.3 yds |
Infrared Control | Yes | |
Housing Material | Polycarbonate, metal end caps | |
IP Rating | IP65 (only with FP1-SP) | |
Ambient Operating Temperature | 0 – 40 °C / 32 – 104 °F | |
Weight | 0.765 kg / 1.68 lbs | |
Dimensions (L x Ø) | 550 mm x Ø 43 mm / 21.7″ x Ø 1.7″ | |
Mounting Options | 2x M5 thread, 2x Holder (with 2x M5 and 1x 1/4″-20UNC thread), 1x TubeStand |
