FEATURES
-
-
- The entire JEM ZR range is compatible with a wide range of JEM Pro fog fluids. As machines designed and built to last, the JEM ZRs will continue to perform with great output and low consumption.
- Small but powerful fog machine
- Exceptional performance and output for its size
- Simple plug-and-play operation via remote control or DMX
- Robust roadworthy design
- Integrated Digital Remote Control
- DMX with RDM
- Floor standing or truss mounting (hanging bracket included)
- 1,150 W heat exchanger
- 600 m³ (21,189 ft.³) per minute fog output
- Variable output control for subtle effects
- Continuous effect output
- Compatible with a wide range of JEM Pro-Fog fluids
- 2.5-l Fluid reservoir with quick-connect fitting
- Easy external fluid connection
- Optional Ducting Kit
-
SPECIFICATIONS
Physical
Length: 485 mm (19.1 in.) Width: 335 mm (13.2 in.) Height: 242 mm (9.6 in.) Height with hanging bracket: 333 mm (13.2 in.) Weight, dry: 11.2 kg (24.7 lbs.) Weight, filled: 13.7 kg (30.2 lbs.)
Performance
Continuous effect output Coverage volume: 600 m3 (21,189 ft3) per minute Fluid consumption (max.): 100 ml per minute Maximum operating time, maximum output, 2.5 l of fluid: 1.2 hours Ready time: 7-minutes
Control and Programming
Control options: Integrated digital remote control, DMX, master/slave link mode Control parameters: Continuous or timer-controlled output Fog: Variable output control, 0-100% DMX channels: 1 External fluid control: Fluid sensing DMX compliance: ANSI E1.11 – USITT DMX512-A RDM compliance: ANSI/ESTA E1.20 RDM
Construction
Housing: Steel and aluminum Hanging bracket: Integrated yoke with safety attachment point Color: Black Heat exchanger: 1150 W, thermally protected Fluid pump: Oscillating piston, high pressure Fluid management: Fluid out sensing, sealed for transportation Fluid reservoir: 2.5 l drop-in reservoir with quick-connect fitting External fluid control: Fluid sensing Remote control: Integrated digital remote with 3 m (9.84 ft.) cable, 3-pin XLR connector
Installation
Mounting: Standing or hanging Orientation: Up to +/-40° from horizontal Clearance around machine: 100 mm (4 in.)
Connections
AC power: Neutrik PowerCON TRUE1 DMX and link mode in/out: 5-pin locking XLR Remote control: 3-pin locking XLR Firmware: AVR socket
Electrical
EU model AC power: 220-240 V nominal, 50/60 Hz Main fuse: 6.3 AT (slow blow), 250 V Typical power and current: 1200 W, 5.3 A* US model AC power: 100-130 V nominal, 50/60 Hz Main fuse: 10 AT (slow blow), 125 V Typical power and current: 1050 W, 8.8 A* *Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
Thermal
Minimum ambient temperature (Ta min.): 5° C (41° F) Maximum ambient temperature (Ta max.): 40° C (104° F) Exterior surface temperature, steady state: 30° C (86° F) Maximum nozzle temperature: 290° C (554° F)
Approvals
EU model EU safety: EN 60 335-1+A15, EN62233 EU EMC: EN 61000-6-3 EU immunity: EN 61000-6-1
