Novastar MCTRL4K LED Screen Processor

Brand:

Novastar

Add to Shortlist
Get in touch to hire

Day Rate

£220.00 +VAT

Week Rate

£440.00 +VAT

The Novastar MCTRL4K LED Screen Processor is a 4 K x 2 K controller.  Adept with a loading capacity up to 3840 x 2160@60Hz for each single unit. It can support any custom resolution within this range as required, thus meeting the on-site configuration requirements of super-wide or super-large LED displays. In Multi-card mode, the controller can be used as two independent controllers. Making the images of two input sources perfectly displayed on the screen. MCTRL4 K also supports HDR function combined with A8s/A10s receiving card to greatly enhance the image quality of the screen. Suitable for use with professional LED screen arrays at festivals or conferences.

Input
DP 1.2
  • DP 1.2 input, with a maximum resolution of 4096×2160@60Hz and minimum resolution of 640×480@24Hz
  • Pixel capacity: 8,800,000 pixels
  • Custom resolutions supported:
    Resolution limit with maximum width: 7680×1080@60Hz
    Resolution limit with maximum height: 1080×7680@60Hz
  • Supports HDCP 1.3.
  • Supported standard resolutions:
    1280×1024@(24/25/30/48/50/60/72/75/85/100/120)Hz
    1366×768@(24/25/30/48/50/60/72/75/85/100/120)Hz
    1440×900@(24/25/30/48/50/60/72/75/85/100/120)Hz
    1600×1200@(24/25/30/48/50/60/72/75/85/100/120)Hz
    1920×1080@(24/25/30/48/50/60/72/75/85/100/120)Hz
    1920×1200@(24/25/30/48/50/60/72/75/85/100/120)Hz
    1920×2160@(24/25/30/48/50/60/72/75/85/100/120)Hz
    2560×1600@(24/25/30/48/50/60/72/75/85/100/120)Hz
    3840×1080@(24/25/30/48/50/60/72/75/85/100/120)Hz
    3840×2160@(24/25/30/48/50/60)Hz
HDMI 2.0
  • HDMI 2.0 input, with a maximum resolution of 4096×2160@60Hz and minimum resolution of 800×600@30Hz
  • Pixel capacity: 8,800,000 pixels
  • Custom resolutions supported:
    Resolution limit with maximum width: 7680×1080@60Hz
    Resolution limit with maximum height: 1080×7680@60Hz
  • Supports HDCP 1.4 and HDCP 2.2.
  • Supported standard resolutions:
  • 1280×1024@(24/25/30/48/50/60/72/75/85/100/120)Hz
    1440×900@(24/25/30/48/50/60/72/75/85/100/120)Hz
    1600×1200@(24/25/30/48/50/60/72/75/85/100/120)Hz
    1920×1080@(24/25/30/48/50/60/72/75/85/100/120)Hz
    1920×1200@(24/25/30/48/50/60/72/75/85/100/120)Hz
    1920×2160@(24/25/30/48/50/60/72/75/85/100/120)Hz
    2048×1536@(24/25/30/48/50/60/72/75/85/100/120)Hz
    2560×1600@(24/25/30/48/50/60/72/75/85/100/120)Hz
    3840×1080@(24/25/30/48/50/60/72/75/85/100/120)Hz
    3840×2160@(24/25/30/48/50/60)Hz
DUAL DVI-D1 DUAL DVI-D2
  • 2 × DVI inputs, each with a maximum resolution of 3840×1080@60Hz and minimum resolution of 800×600@30Hz
  • Pixel capacity: 8,300,000 pixels
  • Custom resolutions supported:

Resolution limit with maximum width: 3840×2160@60Hz Resolution limit with maximum height: 2160×3840@60Hz

  • Supported standard resolutions: 1280×1024@(24/25/30/48/50/60/72/75/85/100/120)Hz 1366×768@(24/25/30/48/50/60/72/75/85/100/120)Hz 1440×900@(24/25/30/48/50/60/72/75/85/100/120)Hz 1600×1200@(24/25/30/48/50/60/72/75/85/100/120)Hz 1920×1080@(24/25/30/48/50/60/72/75/85/100/120)Hz 1920×1200@(24/25/30/48/50/60/72/75/85/100)Hz 1920×2160@(24/25/30/48/50/60)Hz 2560×1600@(24/25/30/48/50/60)Hz 3840×1080@(24/25/30/48/50/60)Hz 3840×2160@(24/25/30)Hz
Output
1–16
  • 16 Neutrik (NE8FBH) Gigabit Ethernet ports
  • Maximum loading capacity of a single Ethernet port:
    • For 8-bit input sources: 650,000 pixels
    • For 10-bit/12-bit input sources: 320,000 pixels
  • Do not support audio output.
  • Support redundancy between Ethernet ports.
OPT1–OPT4
  • 10G optical ports
    • Single-mode twin-core fiber: Support LC optical connectors; wavelength: 1310 nm; transmission distance: 10 km; OS1/OS2 recommended.
    • Dual-mode twin-core fiber: Support LC optical connectors; wavelength: 850 nm; transmission distance: 300 m; OM3/OM4 recommended.
  • The maximum loading capacity of a single optical port equals to that of all the 8 Ethernet ports.
  • 4 OPT inputs/outputs
    • OPT1 and OPT2 are main input/output ports. OPT1 corresponds to Ethernet ports 1–8 and OPT2 corresponds to Ethernet ports 9– 16.
    • OPT3 and OPT4 are backup input/output ports. OPT3 is a duplicate channel of OPT1, and OPT4 is a duplicate channel of OPT2.
Control
ETHERNETFor PC connection
USB INInput port for cascading devices, or connecting to PC
USB OUTOutput port for cascading devices
GENLOCK
INGenlock input connector

  • Genlock type: Blackburst
  • Input Genlock sync signal to ensure synchronization and same refresh rate between the output signals of cascaded MCTRL4K units and the external Genlock signal.
LOOPGenlock loop output connector

Up to 10 MCTRL4K units can be cascaded.

Power
AC 100 V–240 V, 50/60HzAC power input
