Novastar VX4S LED Screen Processor

Brand:

Novastar

Get in touch to hire

Day Rate

£75.00 +VAT

Week Rate

£150.00 +VAT

The NOVASTAR VX4S™ LED Screen Processor is a professional and user friendly LED display controller and a powerful front end processor that supports multiple signal formats including DP / HDMI / VGA / DVI / CVBS / SDI. Supporting up to 1920 x 1200p @60Hz input resolution, the VX4S includes (4) RJ45 outputs for up to 2.6 million pixels of LED control, and supports Nova’s new generation point-by-point correction technology. NOVASTAR VX4S is compatible with all of Elation’s current video products. Suitable for custom events with massive AV requirements, like festivals, concerts and conferences.

Specifications

Collapse All

Inputs
DP 1.1
1
HDMI 1.3
1
Single Link DVI
1
3G-SDI
1
VGA (In)
2
CVBS (In)
2
Outputs
Single Link DVI (Loop)
2
3G-SDI (Loop)
1
VGA (Out)
1
Software Specifications
Control Software
Novastar LCT, Smart LCT
Extra Features
Scaling Function
Yes
Image Mosaic
Yes
Crop Settings
Yes
PIP
Yes
Control and Programming
Control System
Novastar
Maximum Loading Capacity
2300000 Mpx
Maximum Input Resolution
1920 x 1200
Control Options
Ethernet, USB
Electrical Specifications and Connections
Power Supply
100-240 V AC 50/60 Hz
Power Consumption
16 W
Mechanical Specifications
Width (Including Handles)
482 mm
Height (Including Handles)
45 mm
Depth (Including Handles)
275 mm
Weight
2.55 kg
Flightcase Size
19″
Rack Units
1 U
IP Rating
IP20 (indoor use only)
Housing
Aluminium, Metal
Colour
Black
Product Properties
Cooling
Active
Thermal Specifications
Maximum Ambient Temperature
60 °C
Minimum Ambient Temperature
-20 °C
Operating Humidity
0-95 %rH
Included Items
Included Cables
BNC cable, CAT-5 Cable, DP-DP cable, DVI-DVI cable, HDMI-HDMI cable, IEC cable, USB-A – USB-B cable
