Chauvet onAir Panel 2 IP

Brand:

Chauvet

Add to Shortlist
Get in touch to hire

Day Rate

£150 +VAT

Week Rate

£300 +VAT

The Chuavet onAir Panel 2 IP is a large ready to go on-location soft light, designed for broadcast. The onAir Panel 2 IP rating features a superior quality of white light with high CRI and smooth 16-bit dimming curve, that you can take outside. This premium product benefits from easy switch mounting options and accessories and extensive control formats. An optional 28 VDC input via 3-pin XLR powers the fixture from an external battery pack to add increased flexibility. This light provides on-location broadcasts, peace of mind through careful and thoughtful design for remote use.

SPECIFICATIONS

OPTICAL

  • Light Source: 448 LEDs (tri-color RGB) 1.4 W, (150 mA), 50,000 hours life expectancy.
  • Light Source: 448 LEDs (WW) 0.50 W, (150 mA), 50,000 hours life expectancy. Color Temperature (range): 2800 to 8000 K
  • Color Temperature (range): 2800 to 8000 K
  • Color Temperature (at full): 7220 K
  • CRI: 95
  • Beam Angle: 100.2°
  • Field Angle: 157°
  • Lumens: 22,508
  • Illuminance: 349 lux @ 5 m
  • Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz

DYNAMIC EFFECTS

  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Strobe Rate: 0 to 30 Hz
  • Standalone Color Mixing: Yes
  • Color Temperature Presets: Yes
  • Dim Modes: 4
  • Dim Curves: 4
  • Built-in Automated Programs: Yes

CONSTRUCTION / PHYSICAL

  • Dimensions: 33.4 x 5.4 x 21.6 in (849 x 139 x 553 mm)
  • Weight: 37.9 lb (17.1 kg)
  • Exterior Color: Black
  • Housing Material: Aluminum alloy

CONNECTIONS

  • Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
  • Power Input: Seetronic Powerkon IP65
  • Power Output: Seetronic Powerkon IP65
  • Power Input: 28 VDC, 3-pin IP65 XLR
  • Data Connectors: 5-pin IP65 XLR, Seetronic etherCON® Compatible Cable Length (power): 5 ft (1.5 m)
  • Cable Length (power): 5 ft (1.5 m)
  • Software Connection: USB

CONTROL

  • Control Protocol: Art-Net, sACN, DMX, CRMX, RDM
  • DMX Channels: 1, 3, 4, 5, 6, 8, 11, 15, 16, 18, 23 or 32
  • Art-Net Channels: 1, 3, 4, 5, 6, 8, 11, 15, 16, 18, 23 or 32
  • Modes/Personalities: 12 personalities (1, 3, 4, 5, 6, 8, 11, 15, 16, 18, 23, 32)

ELECTRICAL

  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power Linking: 3 units @ 100 V; 4 units @ 120 V; 7 units @ 208 V; 8 units @ 230 V, 8 units @ 240 V
  • Power and Current: 372 W, 3.104 A @ 120 V, 60 Hz
  • Power and Current: 371 W, 1.774 A @ 208 V, 60 Hz
  • Power and Current: 370 W, 1.608 A @ 230 V, 50 Hz

CERTIFICATIONS / QUALIFICATIONS

  • CE, MET, FCC,
  • IP Rating: IP65, temporary outdoor use, with pressure equalizing M12 GORE valve
  • Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C
