Martin Jem ZR25£35.00
Delivery, setup, operation and de-rig all available.
Martin Jem ZR25
Brand:
Martin
Get in touch to hire
Day Rate
£35.00 +VAT
Week Rate
£75.00 +VAT
Description
The JEM ZR25 is a small, yet powerful fog machine designed to deliver superior and uninterrupted performance in demanding professional applications. Via its 1,150 W heat exchanger. The JEM ZR25 features variable output control for more subtle effects. It is also provided with control options, integrated digital remote control, and DMX with RDM. The full 2.5l tank will last approximately 25 minutes at maximum output. This unit produces large amounts of fog, an ideal companion for DJs and bands and effective in small nightclubs that require high output.
Product Video
Technical Specifications
Physical
Length: 485 mm (19.1 in.) Width: 335 mm (13.2 in.) Height: 242 mm (9.6 in.) Height with hanging bracket: 333 mm (13.2 in.) Weight, dry: 11.2 kg (24.7 lbs.) Weight, filled: 13.7 kg (30.2 lbs.)
 Performance
Continuous effect output Coverage volume: 600 m3 (21,189 ft3) per minute Fluid consumption (max.): 100 ml per minute Maximum operating time, maximum output, 2.5 l of fluid: 1.2 hours Ready time: 7-minutes
 Control and Programming
Control options: Integrated digital remote control, DMX, master/slave link mode Control parameters: Continuous or timer-controlled output Fog: Variable output control, 0-100% DMX channels: 1 External fluid control: Fluid sensing DMX compliance: ANSI E1.11 – USITT DMX512-A RDM compliance: ANSI/ESTA E1.20 RDM
 Construction
Housing: Steel and aluminum Hanging bracket: Integrated yoke with safety attachment point Color: Black Heat exchanger: 1150 W, thermally protected Fluid pump: Oscillating piston, high pressure Fluid management: Fluid out sensing, sealed for transportation Fluid reservoir: 2.5 l drop-in reservoir with quick-connect fitting External fluid control: Fluid sensing Remote control: Integrated digital remote with 3 m (9.84 ft.) cable, 3-pin XLR connector
 Installation
Mounting: Standing or hanging Orientation: Up to +/-40° from horizontal Clearance around machine: 100 mm (4 in.)
Connections
AC power: Neutrik PowerCON TRUE1 DMX and link mode in/out: 5-pin locking XLR Remote control: 3-pin locking XLR Firmware: AVR socket
 Electrical
EU model AC power: 220-240 V nominal, 50/60 Hz Main fuse: 6.3 AT (slow blow), 250 V Typical power and current: 1200 W, 5.3 A* US model AC power: 100-130 V nominal, 50/60 Hz Main fuse: 10 AT (slow blow), 125 V Typical power and current: 1050 W, 8.8 A* *Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
 Thermal
Minimum ambient temperature (Ta min.): 5° C (41° F) Maximum ambient temperature (Ta max.): 40° C (104° F) Exterior surface temperature, steady state: 30° C (86° F) Maximum nozzle temperature: 290° C (554° F)
Approvals
PDF Downloads
GET IN TOUCH WITH OUR TEAM TO HIRE
Get in touch with our team, let us know the products you’re looking to hire and the date range you’re interested in. Someone will be in touch shortly with more information.
