Jem Glaciator X-Stream Low Fog

The Glaciator X-Stream houses a remarkably powerful compressor, allowing colossal fog output levels. And because of its advanced, electronically controlled expansion valve, it has a rapid freeze down time and a fast recovery when fired. This means the Glaciator X-Stream has a continuous effect output, almost infinitely, with a cool ease. Its chassis design; with two high velocity fans and smart-flow ventilation, also keeps the Glaciator X-Stream ticking in environments of high ambient temperatures; up to 40° C (104° F). Featuring a power save system when passive, the Glaciator X-Stream is conscientiously efficient with energy and sound, and its cooling fans have a low noise operation when idle, benefiting theatrical and studio applications.

The Glaciator X-Stream has the option of an external fluid supply; allowing voluminous levels of fog fluid to be stored up to 100 meters away from the unit and at a head height of up to 6 meters. Where silence is golden and space is rare, the optional ducting system allows you to place the unit up to 10 meters away from its application area. A great solution, the remote access system does not in any way compromise the fog output density. The JEM™ Glaciator X-Stream is the benchmark in low-fog production for use in touring and installation live performance applications such as theater, nightclubs, television, studio, film production, and live performance.

  FEATURES

Self-contained low-fog solution
Robust feature set
Actors’ Equity/Broadway League Approved
Robust tour-ready industrial design
Self contained unit: no C02 or dry ice
Onboard DMX and PLC control
Dual digital control panels
Density control: low, medium or high
Continuous effect output
Diverse fluid options for differing effects
Internal or external fluid supply
Low fluid sensing
Optional ducting system and remote control

 SPECIFICATIONS

Physical
Length: 866 mmn (34 in.) Width: 638 mm (25.1 in.) Height: 744 mm (29.3 in.) Height without castors: 600 mm (23.6 in.) Weight, dry: 110 kg (242.5 lbs.) Weight, filled: 115 kg (253.5 lb.)

Performance
Coverage volume: 80 m3 (2825 ft3) minute Fluid consumption (max): 110 ml minute Continuous effect output Ready time (min-max): 15-45 minutes, longer cooling period yields colder fog

Control and Programming
Control options: Dual digital control panel, DMX, optional analog remote control, PLC Control parameters: Continuous or timer-controlled output Fog/Density: Proportionally controlled output, 0-100% DMX Addressing: Analog DIP Switches Special Functions: Analog DIP and control switches DMX channels: 2 DMX compliance: ANSI E1.11 – USITT DMX512-A

 Construction
Housing: Steel & aluminum Color: Black and silver Portability: Removable castors Heat exchanger: 3500 W, thermally protected Fluid pump: Dual oscillating piston, high-pressure Fluid management: Fluid out sensing, sealed for transportation Fluid reservoir: 5 l drop-in reservoir or external source External fluid control: Fluid demand, low-fluid sensing Refrigeration: Closed loop system, dual speed condenser fans, electronic expansion valve Refrigeration control: PWM electronic control Refrigerant: R404A, 1.2 kg (2.65 lb.) Optional ducting kit: Black, aluminum, dual ducting adaptor, 2 x 5 m (16.4 ft.), 150 mm (6 in.) flexible ducting included Optional remote control: Analog timer remote control, 3-pin XLR, 5 m (16.4 ft.) cable included Remote control cable length (Max.): 25 m (82 ft.) Optional fluid drain pipe kit: Includes tubing adaptor elbow, and 2 m (6.6 ft.), 6 mm ID, flexible drain hose

Installation
Standing floor use only Orientation: Horizontal Only Clearance around machine: 0.5 m (20 in.) External fluid system (optional): See user manual or contact Martin Professional External fluid tubing (optional): Requires Nylon or PTFE tubing, 10 bar (145 psi) minimum rating Ducting: Optional, max length 10 m (32.8 ft.)

Connections
AC Power (EU model): IEC Pin & sleeve (CEEform), inlet, 32 A, 2P-3W, 220-240 V AC Power (US model): Hardwired flexible mains cable, 3 x 4.0 mm2 (6 AWG), 3.3 m (10.8 ft.) DMX in/out: 3-pin locking XLR Remote control: 3-pin locking XLR PLC Interface/external fluid signaling: D-sub, DB-9, female inlet Firmware: AVR socket External fluid inlet: Push-to-connect tubing inlet, valved, 6mm (0.24 in.) Fluid drain pipe: 8 mm threaded, 1/8” BSP

Electrical
EU Model AC Power: 220 – 240 V, 50 Hz Integrated resettable fuse: 25 A circuit breaker US model AC power: 208 V, 60 Hz Integrated resettable fuse: 25 A circuit breaker
Typical Power and Current
EU model 220 V, 50 Hz: 4483 W, 20.3 A* 230 V, 50 Hz: 4900 W, 21.3 A* 240 V, 50 Hz: 5335 W, 22.23 A* US Model 208 V, 60 Hz: 4200 W, 22.5 A* *Measurements made at nominal voltage. Allow for a deviation of +/- 10%.

Thermal
Maximum ambient temperature (Ta max.): 40° C (104° F) Minimum ambient temperature (Ta min.): 5° C (41° F) Exterior surface temperature, steady state: 50° C (122° F) Maximum nozzle temperature: 200° C (392° F)

Approvals
EU safety: EN 60335-1+A15, EN 62233 EU EMC: EN 61000-6-3 EU Immunity: EN 61000-6-1 Calibration factors have been developed and approved by the Actors’ Equity Association and the Broadway League for use in measuring theatrical fog with the JEM™ Glaciator X-Stream and JEM™ Heavy Fog Fluid, C3.
CE

Included Items
Fluid reservoir 5 l: P/N 34300506 Drip tray: P/N 26564230 Mains power, EU, IEC pin & sleeve connector, 32 A, 2P-3W, 220-240 V: P/N 05327240
