T ECHN I C A L S P E C I F I C A T I O N S
Physical
Length: 602 mm (23.1 in.)
Width: 395 mm (15.6 in.)
Height: 306 mm (12.1 in.)
Height including hanging bracket: 393 mm (15.5 in.)
Weight, dry: 17.7 kg (39.1 lb.)
Weight, filled: 22.7 kg (50 lbs.)
Performance
Coverage volume: 1300 m3 (45,909 ft3) per minute
Fluid consumption (max.): 210 ml per minute
Continuous effect output
Ready time: 10 minutes
Control and Programming
Control options: Integrated digital remote control, DMX, master/client link mode,
optional PLC interface
Control parameters: Continuous or timer-controlled output
Fog: Variable output control, 0-100%
DMX channels: 1
DMX compliance: ANSI E1.11 – USITT DMX512-A
RDM compliance: ANSI/ESTA E1.20 RDM
Construcion
Housing: Steel and aluminum
Hanging bracket: Integrated yoke w/safety attachment point
Color: BlackHeat exchanger (US model): 1800 W, thermally protected
Heat exchanger (EU model): 2000 W, thermally protected
Fluid pump: Dual oscillating piston, high pressure
Fluid management: Fluid out sensing, sealed for transportation
Fluid reservoir: 2.5 l drop-in reservoir with quick-connect fitting
External fluid control: Fluid sensing
Remote control: Integrated Digital Remote with 3 m cable, 3-pin XLR
Installation
Mounting: Standing or hanging
Orientation: Up to +/- 40° from horizontal
Clearance around machine: 100 mm (4 in.)
Connections
AC Power: Neutrik PowerCON TRUE1
DMX and link mode in/out: 5-pin locking XLR
Remote control: 3-pin locking XLR
Firmware: AVR socket
Optional PLC interface: 3- and 4-pin locking XLR
Electrical
EU model:
AC power: 220-240 V nominal, 50/60 Hz
Main fuse: 12.5 AT (slow blow), 250 V
Typical power and current: 2100 W, 9.2 A*
