Showtec ACT Fresnel 50 WW

Day £12.50 + VAT
Week £25 + VAT

Quote: £ 12.50 + VAT

The Showtec ACT Fresnel 50WW is a compact entry-level theatre fixture. It offers great optics and a high CRI level of 98. The LED source is a 50W Warm white module. The Act Fresnel 50WW comes complete with barn door and filter frame. This unit is very well suited for small theatres, school cafeterias or community centres.

  • Compact Design
  • High CRI
  • Manual Zoom
  • DMX controlled
  • High efficiency 50W COB LED source

£12.50

SKU: L-S3-1 Category:

Specifications

Collapse All

Source
Light Source Type  LED
Light Source Quantity  1
Light Source Power  50
LED Colour Type  WW
Refresh Rate  1100
Lux @ 2m  379
Lumen Total  1841
CRI  98
CCT Maximum  3200
Optical
Beam Angle Circular (min)  10
Beam Angle Circular (max)  58
Zoom Type  Manual
Control and Programming
Control Mode  DMX, Manual
DMX Channels  1, 2
Dynamic Effects
Dimmer  0-100 %
Electrical Specifications and Connections
Power Supply  100-240 VAC 50-60 Hz
Power Consumption  57
Power Connector in  powerCON Blue
Power Connector out  powerCON Grey
DMX Connector  XLR 3P In/Out
DMX Connector in  XLR 3P
DMX Connector out  XLR 3P
Mechanical Specifications
Length (mm)  245
Width (mm)  165
Height (mm)  239
Weight  2.4
IP Rating  IP20 (indoor use only)
Housing  Aluminum
Colour  Black
Product Properties
Cooling  Forced Convection
Thermal Specifications
Maximum Ambient Temperature  40
Maximum Surface Temperature  45
Certifications/Qualifications
Reference Standard  CE

L-S3.pdfL-S3 2.pdf
