Shure SM81 – LC

Cardioid condenser instrument microphone offers a wide frequency response and low self-noise. Features include flat response curve, low noise and high output clipping level, low distortion over a range of load impedances, and low RF susceptibility.
Main Features

20 Hz to 20 kHz frequency response
Flat response curve for accurate reproduction of sound sources
Low noise and high output clipping level
Low distortion over a wide range of load impedances
Cardioid polar pattern, uniform with frequency and symmetric about axis, providing maximum rejection and minimum coloration of off-axis sounds
Low RF susceptibility
Selectable low-frequency response: flat, 6 or 18 dB/octave rolloff
0 dB/10 dB lockable attenuator switch
Phantom powering (DIN 45 596 voltages of 12 to 48 Vdc)
Rugged steel construction for durability
Field-usable over wide range of temperature and humidity conditions

£/Day £15.00
£/Week£30.00

Quote: £ 15.00 + VAT

SKU: A-M-D3 Category:

Weight:
230 g
Height x Width x Depth:
212.0 × 23.5 × 23.5 mm
Frequency Response:
20 Hz – 20 kHz
Frequency Response:
Flat
Sensitivity:
-45.00 dBV/Pa – 5.60 mV/Pa
Equivalent Selfnoise:
16 dB typical, A-weighted, 19 dB typical, weighted per DIN 45 405
Sound Pressure:
800 ohm load: 136 dB (attenuator at 0) 146 dB (attenuator at -10), 150 ohm load: 128 dB (attenuator at 0) 138 dB (attenuator at -10)
Transducer Type:
Condenser
Polar Pattern:
Cardioid
Switchable low cut:
Yes
Connectors:
3 Pin XLR
Attenuator:
Yes
Interchangeable Capsule:
No
Main Functionality:
Performance
Headphone Output:
No
Requires Phantom Power:
11 – 52 VDC
Cartridge:
Fixed
