Chauvet Rogue Outcast 1 BeamWash

Day £85 + VAT
Week £170 + VAT

Quote: £ 85.00 + VAT

Rogue Outcast 1 BeamWash is a lightweight, IP65 rated, LED Beam & Wash fixture enhanced with a pixel-mappable LED ring around it’s face. A unique lens design developed for tight beam effects allows for a wide zoom range of 3.9° to 55.3° for maximum coverage. Seven 45W RGBW LED’s combine excellent color mixing with a punchy output featuring 16-bit dimming and several dimming modes for advanced control. The outer ring comprises of 12 pixel-mappable RGB LED zones underneath a smoked stealth filter. Easily create eye-catching effects with prebuilt programs for the ring with the ability to control dimming, rate, foreground and background colors. This compact fixture weighs only 20lbs and features a rugged IP65 casing that is proven to withstand all of the harshest elements. Control as you see fit with multiple profiles with simple and advanced control modes compatible with DMX & RDM protocols. Update software easily with an onboard USB-C port.

£85.00

          SPECIFICATIONS

OPTICAL

    • Field Angle: 5.9° to 49.8°
    • Cutoff Angle: 6.7° to 55.3°
    • Zoom Range: 3.9° to 55.3°
    • Lumens – Source: 5,900
    • Lumens – Output: 4,073
    • Illuminance (3.9°): 15,308 lux @ 5m
    • Illuminance (55.3°): 473 lux @ 5 m
    • Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz

DYNAMIC EFFECTS

    • Pan and Tilt: 540°/260°
    • Pan and Tilt Ranges: 180°, 360°, 540° pan/90°, 180°, 260° tilt
    • Dimmer: Electronic
    • Shutter/Strobe: Electronic
    • Zoom: Motorized
    • Strobe Rate: 0 to 20 Hz
    • Standalone Color Mixing: Yes
    • Color Temperature Presets: Yes
    • Dim Curves: 4
    • Built-in Automated Programs: Yes
    • Customizable Programs: yes
    • Recall Custom Programs: No

CONSTRUCTION / PHYSICAL

    • Dimensions: 11.92 x 7.58 x 15.75 in (303 x 192 x 391 mm)
    • Weight: 20.2 lb (9.16 kg)
    • Exterior Color: Black
    • Housing Material: Magnesium aluminum diecast, high impact, flame-retardant polymer

CONNECTIONS

    • Power Connection: Edison plug to Seetronic Powerkon IP65
    • Power Input: Seetronic Powerkon IP65
    • Power Output: Seetronic Powerkon IP65
    • Data Connectors: 5-pin XLR
    • Cable Length (power): 5 ft (1.5 m)

CONTROL

    • Control Protocol: DMX, RDM
    • DMX Channels: 15, 24, 30, 64, 111 or 135
    • Modes/Personalities: 6 personalities (15, 24, 30, 64, 111, 135)

ELECTRICAL

    • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
    • Power Linking: 4 units @ 120 V; 7 units @ 208 V; 7 units @ 230 V
    • Power and Current: 385 W, 3.25 A @ 120 V, 60 Hz
    • Power and Current: 376 W, 1.92 A @ 208 V, 60 Hz
    • Power and Current: 372 W, 1.69 A @ 230 V, 50 Hz
    • Fuse Size: 8A, 250 V

CERTIFICATIONS / QUALIFICATIONS

    • CE, MET, FCC
    • IP Rating: IP65, temporary outdoor/wet use, with pressure equalizing M12 GORE valve
    • Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
    • Maximum Exterior Surface Temperature (Tc): 80° C / 176° F
    • Maximum Ambient Temperature (ta) 45° C / 113° F

WHAT’S INCLUDED

    • Rogue Outcast 1 BeamWash
    • Seetronic Powerkon IP65 power cord
    • (2) Omega brackets with mounting hardware

OPTIONAL ACCESSORIES

    • Professional Clamps: CTC-50HC, CTC-50HCN
    • Safety Cable: SC-07
    • IP Rated Seetronic® Powerkon Extensions
    • DMX Cables
    • Flight Case:
    • UPLOAD 08 software uploader

Rogue_Outcast_1_Beam_Wash_UM_Rev2.pdf
