Robe Spiider

Spiider, a superbright next generation of LED WashBeam luminaires, using 18x 30 Watt and 1x 60 Watt LEDs and combining it with a very efficient 12,5:1 zoom optical system ranging from tight 4° Beam to wide 50° Wash, makes the product the most powerful LED fixture on the market.

Beautiful convergence of hard edge in-air effects, punchy beams and smooth homogenized wash is all encapsulated in the unique Spiider.

Rich colors of 19 powerfull RGBW LEDs can create charming wash light with velvety smooth transitions thanks to internal 18bit LED dimming system.

Dynamic video effects are easily achieved by mapping individual pixels and controlled by DMX desk or media servers via sACN with internal HTP merging, DMX or by Kling-Net protocol.

Unique central piece with Robe exclusive Flower Effect is driven by 60W RGBW LED multichip for new innovative sharp multicoloured spikes of light, rotating in both directions at variable speed, adding another new visual effect to the show.

Price£65.00
£/Week£130.00

Quote: £ 65.00 + VAT

£65.00

SKU: L-MS13 Category:

LIGHT SOURCE
1x 60W RGBW and 18 x 30W RGBW LED multichips

LIGHT OUTPUT
11.000 lm, 50.100 lx @ 5m

ZOOM RANGE
4° – 50°

EFFECTS
pixel control, flower effect, virtual colour wheel, tungsten lamp effect, preprogrammed pixel effects

SOURCE
Light Source Type: 1x 60W RGBW and 18x 30W RGBW LED multichips
LED Life Expectancy: min. 20 000 hours
Typical Lumen Maintenance: 70% @ 20 000 hours
OPTICAL SYSTEM
Robe’s proprietary optical design
High – efficiency zoom optical system, ratio 12,5:1
Zoom range: 4° – 50°
Fixture total lumen output: 11.000 lm
Light output: 50.100 lx @ 5 m
DYNAMIC EFFECTS
Colour mixing mode RGBW or CMY
Individual control of each RGBW pixel
Variable CTO: 2.700K – 8.000K
Virtual Colour Wheel: with 66 preset swatches
Tungsten lamp effect at whites: 2.700K and 3.200K (red shift and thermal delay)
Colour rainbow effect with variable speed
Pre-programmed pixel effects with colour, dimming and strobe chases, waves and pulses at variable speed and direction
Innovative Flower Effect: rotating in both directions at variable speed (patent pending)
Strobe effect: variable speed (max. 20 flashes per second)
Pre-programmed random strobe & pulse effects
High resolution electronic dimming: 0 – 100%
CONTROL AND PROGRAMMING
Setting & Addressing: ROBE Navigation System 2 (RNS2)
Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 100 steps), built-in analyser for easy fault finding
Protocols: USITT DMX-512, RDM, Art-Net, MA Net, MA Net2, sACN, Kling-Net
Wireless CRMX™ technology from Lumen Radio (on request)
DMX Protocol modes: 10
Control channels: 49, 27, 33, 90, 27, 46, 91, 110, 103, 123
Pan/Tilt resolution: 16 bit
R,G,B,W colour mixing: 8 or 16 bit (internal 18 bit)
Zoom: 8 bit
Dimmer: 8 or 16 bit (internal 18 bit)
MOVEMENT
Pan movement: 540°
Tilt movement: 220°
Movement control: Standard and Speed
Controllable speed of Pan/Tilt movement
EMS™: Electronic Motion Stabilizer system for Pan & Tilt reducing beam deviation caused by truss movement or vibration (Patent pending)
Automatic Pan/Tilt position correction
THERMAL SPECIFICATION
Maximum ambient temperature: 45 °C (113 °F)
Maximum surface temperature: 75 °C (167 °F)
Minimal operating temperature: – 5°C (23 °F)
ELECTRICAL SPECIFICATIONS AND CONNECTIONS
Power supply: Electronic auto-ranging
Input voltage range: 100-240 V, 50/60 Hz
Power consumption: max. 600 W
Power in connector: Neutric powerCON TRUE1
DMX and RDM data in/out: Locking 3-pin & 5-pin XLR
Ethernet port in/out: RJ45
Embeded Ethernet switch 10/100 Mbps: 1 x in / 1 x out
APPROVALS
CE Compliant
cETLus Compliant (pending)
MECHANICAL SPECIFICATION
Height: 477 mm (18.7”)
Width: 390 mm (15.3”)
Depth: 252 mm (9.9”)
Weight: 13,3kg (29.2 lbs)
RIGGING
Mounting positions: Horizontally or vertically
Universal operating position
Mounting points: 2 pairs of 1/4-turn locking points
2x Omega adaptors with 1/4-turn quick locks
Safety cable attachment point
Tilt transport lock
