Portman P3 PIX3L£50.00
Delivery, setup, operation and de-rig all available.
Portman P3 PIX3L
Brand:
Portman
Get in touch to hire
Day Rate
£50 +VAT
Week Rate
£100 +VAT
Description
The Portman P3 PIX3L is small but crazy. This three-channel fixture is widely used as part of scenography, as a powerful blinder on all parts of stages and can also be used for lighting artists.
- 3 DMX channels – The P3 PIX3L operates on 3 DMX channels, providing you with full control over the three individual halogen lamps. This allows you to easily integrate it into existing lighting setups and manage each channel separately for precise effects.
- 3 x 230W halogen lamps – Powered by three 230W halogen lamps, this fixture offers high brightness and a rich warm light output. It is perfect for blinding effects, accent lighting, and scenography uses.
- Built in dimmers and electronics
- 5-PIN XLR connectors
- RDM and WDMX* (*as an optional module)
- Can be easily installed on any tripod or hang on any clamp
_________________________________________________________________________________________________________________________________
Looking for more decorative lighting perfect for any large event – like a product launch or a private party… then check out our Decorative lighting page here
Product Video
Technical Specifications
| Dimensions | 45 x 40 x 20 cm (17.7 x 15.7 x 7.9 in) |
|---|---|
| Weight | 4,5 kg (9.9 lbs) |
| Rigging | 12 mm (1/2 in) hole for spigot or clamp |
| Mounting position | Any |
| Input voltage | 230V 50Hz/60Hz |
| Power consumption | max 690W |
| Power connector | Neutrik PowerCon TRUE1 |
| Control connector | Neutrik 5 PIN XLR (both: in & out) |
| Light sources | 3 x halogen R7s 118mm OSRAM Haloline PRO 230V 230 W (high efficiency) |
| Color temperature | 1 600 – 2 900K |
| CRI | 100 |
| Optics | High reflective hammered reflector |
| Control features | – 3 DMX channels – RDM – W-DMXÂ (additional option, can be upgraded any time later) |
| User interface | – High-contrast LCD display – Highlighted buttons |
| Other details | – silver reflector (standard, can be swapped) – gold reflector (additional option, can be swapped) – flight cases (8,12-row) (additional option) |
| Warranty | 24 months |
| IP rating | IP20 |
| What’s in the box | – Fixture – 2m power cord (PowerCon <-> no plug, naked ends) – user manual – 1x spare lamp |
| Libraries: | GrandMA2, ChamSys, ADJ MyDMX, Avolites Titan, Wysiwyg, Vectorworks, Capture, Realizzer… (download here) |
PDF Downloads
Recommended Accessories
Complete your lighting set up with our top-notch accessories
You may also like...
GET IN TOUCH WITH OUR TEAM TO HIRE
Get in touch with our team, let us know the products you’re looking to hire and the date range you’re interested in. Someone will be in touch shortly with more information.
