Optical
LCD Panel
0.59″ (1.5cm) P-Si TFT x 3

Resolution
WXGA (1280 x 800)

Brightness
3100 ANSI Lumens (Normal Mode) / 2542 ANSI Lumens (Eco Mode 1) /
2077 ANSI Lumens (ECO mode 2)

Contrast Ratio
10000:1

Lens
Manual focus, digital zoom x 1.35

Lamp Wattage
225W UHP

Lamp Life
5000 hours (Normal Mode) / 8000 hours (Eco1) / 10000 (Eco2)

Focus Distance
0.735m ~ 1.953m

Distance To Width Ratio
0.6

Diagonal Display Size
60~150″ (152~381cm)

Keystone Correction
Fixed 5.6:-1 upward shift, Normal at + 36.6° projection angle

Number Of Colours
8 Bit/colour, 16.7M colours

Compatibility
Computer Compatibility
IBM Compatible VGA, SVGA, XGA, WXGA/WXGA+/SXGA/SXGA+/UXGA (compressed) MAC16”

Composite/S-Video
NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43

Component Video/HDMI
525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60), 750p(720p@50/60), 1125p(1080p@50/60)

Plug & Play
DDC2B

Features
Speakers
10W x 1 (mono)

Basic Functions
Freeze, Magnify, Blank, Aspect selection, Auto signal search, Auto eco mode

Picture Adjustments
2-3 Pull Down for NTSC, Digital image shift (vertical), Equalizing colour temperature adjustment, Equalizing digital gamma correction, Mirror reverse image, Up-side down image, Video noise reduction

Digital Keystone Correction (Degrees)
Vertical: ±5°

Advanced Features

Audio ports assign, closed caption (for NTSC & 480i), drawing function (requires TB-1 wireless interactive tablet, Eco Mode (normal, Eco, intelligent eco, saver), filter timer, frame lock, My Button by remote control, My Memory, My Source, My Text, MyScreen, overscan, PC-less presentation, picture mode (normal, cinema, dynamic, board (black), board (green), whiteboard, daytime, photo), progressive scan, resolution setting, source naming (English), standby audio, template, USB Display, ImageCare™, cloning function, iOS connectivity,Android connectivity

Outward
Easy lamp replace from top, easy access air filter

Power On & Off
Direct power on, Auto power off

Security Systems
Security bar, PIN security lock, MyScreen password lock, My text password lock, Key lock (keypad, remote control), serial number on front of projector, Kensington slot

Network
Project Monitoring (Wired LAN), Control from Remote Location (Wired LAN), E-mail alerts
(Wired LAN), mirroring of PC screen (used the LiveViewer soft), infrastructure mode
(Wireless LAN), Adhoc mode (Wireless LAN), SNMP Management (SNMP), cloning function,
easy schedule setting

OSD Languages
English, French, German, Spanish, Italian, Norwegian, Dutch, Japanese, Portuguese, Simplified Chinese, Traditional Chinese, Korean, Swedish, Russian, Finnish, Polish, Turkish, Arabic, Persian, Czech, Danish, Hungarian, Romanian, Slovenian, Croatian, Greek, Lithuanian, Estonian, Latvian, Thai, Portuguese (Brazil), Indonesian, Vietnamese

Connections
Digital Input
2 x HDMI (HDCP compliant)

Computer Input
2 x 15-pin Mini D-sub

Computer Output
1 x 15-pin Mini D-sub

Video Input
1 x RCA composite, 1 x S-Video, 2 x component (shared with analogue computer in 1/2)

Audio Input
3.5mm stereo mini connector, 1 x pair RCA (L/R)

Audio Output
1 x 3.5mm stereo mini connector

USB
2 x USB type A (PC-less presentation or optional wireless adaptor)
1 x USB type B (USB mouse control or USB display)

Control
1 x 9-pin D-sub for RS232C Control

Wired Network
1 x RJ-45

Wireless LAN
Optional wireless adapter required

Power
Power Supply
100-120V/220-240V, auto switching

Power Consumption/Standby
300W/<0.35W (AC 220-240V)

Dimensions (W X H X D)
345 x 85 x 303mm (excluding feet and extrusions)

Weight
3.6Kg

Noise Level
37dB (Normal Mode) / 32dB (Eco1) / 29dB (Eco2)

Operating Temperature
0~40°C

Air Filter
Hybrid (up to 5000 hours)

Miscellaneous
Miscellaneous
MAC address displayed on the front of projector

Certification
Certification (CP-CX250)
UL, CB, GS, AUS, Fcc, c-tick, CE, DoC
