7500L Panasonic PT-EX800Z

High Brightness, Low TCO, and Flexible Installation for Versatile Use

High Brightness and Superb Image Quality

The Daylight View Basic Funtion Ensures Clear Images Even in Brightly Lit Rooms

Panasonic‘s Daylight View Basic technology achieves sharp, easy-to-see images by clearly reproducing the details in dark image areas, which were previously difficult to see in brightly lit rooms. A built-in sensor measures the ambient light, and the Daylight View Basic function adjusts the halftone color and brightness level according to the surrounding illumination.

£/Day £325.00
£/Week£650.00

Quote: £ 325.00 + VAT

SKU: AV-P7 Category:

Despite its sleek and compact dimensions, the PT-EZ770 Series produces a class-leading 6,500 lm to 7,500 lm* of brightness with a contrast ratio of 5,000:1. The iris automatically adjusts to suit ambient lighting conditions.

* The PT-EX800Z/EX800ZL has 7,500 lm, the PT-EW730Z/EW730ZL has 7,000 lm, and the PT-EZ770Z/EZ770ZL has 6,500 lm of brightness.

WUXGA Resolution for Lustrous Full HD Images (PT-EZ770ZE)

With native WUXGA 1,920 x 1,200 pixel widescreen resolution, the
PT-EZ770Z/EZ770ZL is capable of displaying Full HD video from Blu-ray Disc and other sources in beautifully rich, vivid detail.

– 7.500 lm of brightness in a compact body
– XGA (1.024 x 768) rsolution
– High contrast ratio of 5.000:1

Brightness: 7,500 Lumens
Color Light Output: **
Contrast: 5,000:1
Auto Iris: No
Resolution: 1024×768
Aspect Ratio: 4:3 (XGA)

Video Modes: 720p, 1080i, 1080p/60, 1080p/24, 1080p/25, 1080p/50, 525i, 525p, 576i, 576p, 625i, 1125i, 480p, 480i
Data Modes: MAX 1920×1200

Max Power: 575 Watts
Voltage: 100V – 240V

Size(cm) (HxWxD): 18 x 53 x 39
Weight: 10.6 kg

Connection
Panel: Composite (RCA)
S-Video
VGA In (Dsub-15pin)
DVI Digital Input
RGB In (BNC)
HDMI
Audio Out (Mini Jack)
Network (RJ-45)
RS232 (DB-9pin)
DisplayPort
HDBaseT (RJ-45)
Audio In (Mini Jack)
VGA Out (Dsub-15pin)
Audio In (RCA)

** item is not applicable, unpublished, or unknown
Lamp Life(Full Power): 3,000 hours
Lamp Life(eco-mode): 4,500 hours
Lamp Type: UHM
Lamp Wattage: 400 Watts
Lamp Quantity: 1

Display Type: 2 cm 3 LCD

Standard Zoom Lens: Powered, 1.70:1
Standard Lens Focus: Powered
Optional Lenses:
Panasonic ET-ELT20 Zoom Lens 2.80:1-4.60:1
Panasonic ET-ELT21 Zoom Lens 4.60:1-7.20:1
Panasonic ET-ELW20 Zoom Lens 1.30:1-1.70:1
Panasonic ET-ELW21 Fixed Lens 0.80:1
Panasonic ET-ELW22 Short Throw Zoom Lens 0.80:1-1.00:1
Lens Shift: Horz & Vert

Throw Dist (m): 2.3 – 13.5
Image Size(cm): 102 – 1016
Throw Ratio(D:W): 1.67:1 – 2.83:1

Audible Noise: 37.0 dB
Eco-Mode: 29.0 dB

Speakers: 10.0 W Mono
Digital Zoom: Yes
Digital Keystone: Horz & Vert
