Hardware Specifications:
-
-
-
- Universes supported: 4
- Direct DMX Outputs 5-Pin XLR: 2
- 10Scene buttons: 10
- External Monitor: 1920 x 1080 HDMI
- Inbuilt Wi-Fi: Yes
- Network Port: 1
- USB Ports: 2
- Audio Input: 1
- Audio Output: 1
- MIDI Ports in/out: Yes
- TrueCon Power Input: 90-250v AC
-
-
Rack Weights and Dimensions:
-
-
-
- Width (without ears): 403mm (15.8 inches)
- Depth: 195mm (7.7 inches)
- Height: 45mm (1.8 inches)
- Weight: 3.1kg (6.8 lb)
-
-
Boxed Weights and Dimensions:
-
-
-
- Width: 480mm (18.9 inches)
- Depth: 330mm (13.0 inches)
- Height: 150mm (5.9 inches)
- Weight: 4kg (8.81 lb)
-
-
Software Specifications:
-
-
-
- Max Number of DMX Channels: 2048
- Max Number of Fixtures Supported: 2048
- Max Number of Scenes: 10
- Midi & Midi Timecode Supported: Yes
- OSC Supported: Yes
- RDM Autopatch for fast show patching
- Fixture library of over 30,000 fixture files
- Built in FX generator
- Colour picker and Gel inbuilt Gel library
- Offline designer software available for Windows and Mac
- Supported fixtures: All – LEDs, Dimmers & Moving Lights
-
-
Included Accessories:
-
-
-
- Wi-Fi Antenna: 1
- Rackmount Ears: 2
- 10Scene Connectors: 4
- Neutrik powerCON TRUE1 Power Cable: 1
-
-
