Robe Pointe

It’s very bright and super-fast with a sharp parallel beam that cuts through the air and across video with ease.

It can project a static or rotating glass gobo to produce precision in-air and surface images with an even focal plane. Tight or at full 20 degree zoom, the output is crystal clear and brilliant. Add in either rotating, 6 way linear or 8 way circular, prisms to create wide reaching effects across any set.

Drop in the frost filter and use any of the 13 rich colours to create a smooth even wash. The Pointe has an output far greater in size, quality and power than seems possible from it’s small, lightweight body – due to the efficient short arc 280 W discharge source and the Robe optical configuration. This new technology fixture even travels efficiently in a case of 4 and will cover all your needs – Beam, Spot, Wash, FX – there is no point in using any other fixture.

£/Day £65.00
£/Week£130.00

Quote: £ 65.00 + VAT

SKU: L-MS12 Category:

LIGHT SOURCE
Osram Sirius HRI 280W RO

LIGHT OUTPUT
Beam mode: 9.870 lm, 82.400 lx @ 20 m; Spot mode: 5.150 lm, 90.000 lx @ 5 m

ZOOM RANGE
2, 5° – 10° Beam mode, 5° – 20° Spot mode

EFFECTS
rotating and static gobo wheel, circular 8-facet and linear 6-facet prism

SOURCE
Lamp: Discharge short arc lamp with integrated reflector
Approved model: Osram Sirius HRI 280 W RO
Lifetime: Standard mode (280 W) – 2.000 hrs, Eco mode (230 W) – 3.000 hrs
CRI: 75
CCT: 7000 K
Control: Automatic and remote on/off
Ballast: Electronic
OPTICAL SYSTEM
Robe’s proprietary optical design
Zoom range:
2.5°-10° beam application
5° – 20° spot application
Output lens diameter: 110 mm
Fixture total lumen output:
Beam mode: 9.870 lm
Spot mode: 5.150 lm
Light output:
Beam mode: 82.400 lx @ 20 m
Spot mode: 90.000 lx @ 5 m
DYNAMIC EFFECTS
Colour wheel: 13 dichroic filters + white
Rotating Gobo wheel: 9 rotating, indexable and replaceable “SLOT&LOCK” glass gobos + open
Static Gobo wheel: 14 gobos + open
Prism 1: 8-facet circular prism rotating in both directions at different speeds
Prism 2: 6-facet linear prism rotating in both directions at different speeds
Frost effect: Separate, variable
Motorized zoom and focus
Pre-programmed random strobe & pulse effects
Dimmer: 0 – 100%
CONTROL AND PROGRAMMING
Setting & Addressing: ROBE Navigation System 2 (RNS2)
Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC
3-editable programs, each up to 100 steps
Stand-alone operation
Protocols: USITT DMX-512, RDM, ArtNet, MA Net, MA Net2, sACN
Wireless CRMX™ technology from Lumen Radio: On request
DMX Protocol modes: 3
Control channels: 24, 16, 30
Pan/Tilt resolution: 8 or 16 bit
Colour wheel positioning: 8 or 16bit
Rotating gobo wheel positioning: 8 bit
Gobo indexing & rotation: 8 or 16bit
Static gobo wheel positioning: 8 bitt
Frost: 8 bit
Zoom: 8 or 16bit
Focus: 8 or 16bit
Dimmer: 8 or 16bit
MOVEMENT
Pan movement: 540°
Tilt movement: 270°
Controllable speed of Pan/Tilt movement
ROTATING GOBOS
Glass gobos: 9 rotating gobos
Outside diameter: 15.9 mm
Image diameter: 12.5 mm
Thickness: 1.1 mm
High temperature borofloat or better glass
“SLOT&LOCK” system for easy replacement of gobos
STATIC – BEAM GOBOS
Aluminium wheel with fixed gobos: 10 gobos & 4 beam reducers
THERMAL SPECIFICATION
Maximum ambient temperature: 45°C (113°F)
Maximum surface temperature: 90°C (194°F)
ELECTRICAL SPECIFICATION AND CONNECTIONS
Power supply: Electronic auto-ranging
Input voltage range: 100-240 V, 50/60 Hz
Power consumption: 470 W at 230 V / 50 Hz
Power in connector: Neutrik powerCON
DMX and RDM data in/out: Locking 3-pin & 5-pin XLR
Ethernet port in/out: RJ45
APPROVALS
CE Compliant
cETLus Compliant
MECHANICAL SPECIFICATION
Height: 575 mm (22.6″) – head in vertical position
Width: 364 mm (14.3″)
Depth: 250 mm (9.8″)
Weight: 15 kg (33 lbs)
RIGGING
Mounting points: 2 pairs of 1/4-turn locks
2x Omega adaptors with 1/4-turn quick locks
Universal operating position
Pan and Tilt transport locks
Safety cable attachment point
INCLUDED ITEMS
User Manual
Power cord including powerCON In connector
ACCESSORIES
Lamp Osram Sirius HRI 280W RO: 14080047-01
Doughty Trigger Clamp: 17030386
Safety wire 35 kg: 99011963
Single Top Loader Case: 10120140-01
Dual Top Loader Case: 10120146-01
Quad Top Loader Case: 10120139-01
Foam Shell: 20020191
LEGAL
Pointe® is a registered trademark of Robe lighting s. r. o.
Pointe® is patented by Robe lighting s. r. o. and is protected by one or more pending or issued patents
