Pixel Pitch | 2.6mm |
Environment | Indoor |
LED Type | 3-in-1 Black SMD |
Brightness | 800 cd/m² |
Pixel Density | 147,456 pixels/m² |
Module Size (W×H) | 250mm × 250mm |
Panel Size (W×H×D) | 500mm x 500mm x 83mm |
Panel Resolution | 192 x 192 dots |
Panel Weight | 7.9 kg |
Material | Die-cast Aluminum |
Ingress Protection | IP30 |
Operating Temperature/Humidity | -10°Cto45°C/10% – 80% RH |
Maintenance | Rear |
Curve (Convex – Concave) | -10° to 10° |
Viewing Angle (H/V) | 140°/120° |
Contrast Ratio | 3,000:1 |
Input Power/Panel (Max.) | 120 W |
Input Power/Panel (Ave.) | 35 W |
Refresh Rate | 3,840 Hz |
Input Voltage | 100 – 240 VAC |
Input Power Frequency | 50 – 60 Hz |
Standard Mounting Configuration | Hanging, Stacking |
