Source | Type: | Semiconductor laser diode | 10x static red laser beam | 10x 3-Watt LED blinder |
Suitability: | Indoor laser displays / Stage lighting |
System control: | DMX512, Auto-mode, Sound-to-light |
Compliant with: |
EN 60825-1, Class 3B |
Weight [kg]: | 4 |
Size [WxHxD, mm]: |
1000 x 50 x 166 |
Guaranteed opt. output [mW]: | 200 [per each laser output] |
R | G | B [mW]: |
200 | – | – |
Wavelengths [nm, ±5nm]: |
638 | – | – |
Beam size [mm]: | 4 |
Beam divergence [mrad]: |
1.8 [full angle] |
Modulation [kHz] | type: | 30 | analogue |
X-Y scanners: | – |
Power requirements [V] | Input: |
100-230/50-60Hz | Neutrik powerCON |
Max. power consumption [VA]: | 250 |
Operation temperature [°C]: | 10-40 |
Ingress Protection rating [IP]: | 20 |
Included in the set: |
1.5M power lead, user manual. |
Kvant Red-laser LED bar
The Kvant Red-laser LED bar is minimalistic, yet produces powerful effects.
10x static RED laser beam
10x 3W LED blinder
DMX and Sound-to-light control
Check our range of LED battens for more effects and inspiration
£75.00
